Scorpion 72 – 2hp Fixed speed
$859.32 Inc. GST
The Scorpion is the Australian made belt grinder for entry level knife makers to professional blacksmiths. With more power, more speed, big platen and small footprint; the Scorpion grinder is in a league of its own.
Description
Scorpion GRINDER
The Scorpion known for its fast acting, effective sting; this grinder is no different. With more power, more speed, big platen and small footprint; the Scorpion grinder is in a league of its own. Perfect for both beginners and professionals.
Features include:
- 2 x 72” or 2 x 48” Belt Capacity
- Solid 10mm steel frame, laser cut for accuracy
- Bisalloy platen backrest
- 6061 aluminium tracking and drive wheels
- Huge 250mm drive wheel coupled with 2hp and 3hp motors ultimate performance
- The only grinder in its class built to run the Cubitron II belts from 3M
- Extended length platen backrest for greater control
- Move from a 300mm flat platen to a 250mm slack belt without even stopping or making adjustments
- 150 – 350mm contact wheel capability
- Australian designed and built
Model comparison
| Model | SC72 Frame | SC72 2hp | SC72 3hp | SC72 VSD |
| Dimension of Frame (LxWxH) | 250 x 400 x 850mm | 250 x 400 x 850mm | 250 x 400 x 850mm | 250 x 400 x 850mm |
| Weight | Approx. 20kg | Approx. 35kg | Approx. 35kg | Approx. 40kg |
| Electrical Specifications | – | 240v 10a | 240v 15a | 240v 10a |
| Belt Size | 2 x 72” | 2 x 72” | 2 x 72” | 2 x 72” |
| Belt Speed | – | 7500sfm fixed | 7500sfm fixed | 750 – 7500sfm |
| Environment | – | IP55 | IP55 | IP55 (indoor only) |
| Motor | No Motor | 2 hp, 2 pole | 3hp, 2 pole | 2hp, 4pole |
| Switchgear | – | DOL Starter | DOL Starter | VSD control |
